10A High Precision Portable Transformer DC Winding Resistance Tester

Wuhan Mingyang Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

10A High Precision Portable Transformer DC Winding Resistance Tester

Delivery Time : 1 week

Measurement accuracy : 0.5%

Weight : 12kg

Data storage : Group of 1000

Temperature : 0℃~40℃

Model Number : MYRB

Accuracy Class : 0.5%

Protection Class : IP55

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Place of Origin : China Mainland

Volume : 380*350*260 mm

Type : Testing Instruments

Price : 900usd

Packaging Details : carton

Current Resolutio : 1μΩ

Measurement range : 1-1999μΩ

Voltage : 50v

Supply Ability : 1000pcs/month

Resolution : 1μΩ

Display mode : three-and-a-half-digit LCD

Application : Electrical Testing

Power : 200W

Operating Temperature : -10℃~40℃

Conversion temperature : 20℃~150℃

MOQ : 1

Time Resolution : 1s

Output current : auto,10A

Working power supply : AC220V ± 10%, 50Hz ± 1Hz

Brand Name : MINGYANG

Measuring Range : 1-1999μΩ

Warranty : 2 Year

Contact Now

10A High Precision Portable Transformer DC Winding Resistance Tester

Basic Info.

Model NO.
MYRB
Display Type
Digital Only
Certification
CE
Customized
Customized
Model No.
MYRB
Output Current
Auto,<5mA,<20mA,40mA,200mA,1A,5A,10A
Accuracy
2‰±2μω
Resolution
0.1μω
Operating Temperature
-20-40 ºC
Ambient Humidity
≤80%Rh, Non-Condensing
Power Supply
AC 220V±10V,50Hz±1 Hz
Max. Power Consumption
200W, Optional Battery
Measurement Range
1μω-2kΩ
Weight
6.45kg
Dimension
360*290*170mm
Transport Package
Wooden Box
Specification
360*290*170mm
Trademark
MINGYANG
Origin
Wuhan, China
HS Code
9030332000
Production Capacity
1000/Year

Product Description

MYRB transformer DC resistance is the transformer manufacturing semi-finished products, finished products factory test, installation, overhaul, change the tap changer, after the handover test and power department preventive test must be measured items. It can check the welding quality of the winding joints and whether there is any turn-to-turn short-circuit in the winding, whether the contact of each position of the voltage tap-changer is good and whether the actual position of the tap-changer matches with the indicated position, whether there is any fracture of the lead wire, whether there is any breakage of multi-stranded conductors in parallel winding and whether there is any breakage of strands and so on. In order to meet the needs of transformer DC resistance rapid measurement, our company developed the HZP-10B DC resistance tester. The instrument adopts new power supply technology, featuring small volume, light weight, large output current, good repeatability, strong anti-interference ability, and perfect protection function, etc. The whole machine is controlled by high-speed microcontroller. The whole machine is controlled by high-speed microcontroller, with high degree of automation, automatic discharge and discharge alarm function. The instrument has high testing precision, easy operation, and can realize the rapid measurement of transformer direct resistance.

Product Features
  • High output current instrument with lightweight design
  • Six output current options with maximum output of 10A
  • Wide measurement range from 0.5mΩ to 100KΩ with resistance temperature conversion capability
  • Comprehensive protection circuit for reliable performance
  • Lithium-ion battery powered for convenient field operation
  • Sound discharge alarm to reduce operational errors
  • AC and DC measurement methods to meet different site requirements
  • 4.3-inch color LCD TFT display with 480*272 resolution and Chinese operation menu
  • Real-time printing and output results
  • RS485 interface for test data transmission to background systems
  • Local storage capacity for up to 200 test records
  • USB interface for data transfer to USB drives
  • Comprehensive parameter settings including transformer test winding, tap position, test phase, and temperature values

Pruduct Parameters

Output Current Levels Auto,<5mA, <20mA,40mA,200mA,1A,5A,10A
Measurement Range 10A:0.5mΩ~800mΩ
5A:2mΩ~2Ω
1A:5mΩ~10Ω
200mA:100mΩ~50Ω
40mA:500mΩ~250Ω
±(0.2%+2 digits)
Accuracy
<20mA: 50Ω~50KΩ
±(0.5%+2 digits)
Min. Resolution
0.1μΩ
Operating Temperature
-20~40ºC
Ambient Humidity
≤80%RH, non-condensing
Power Supply
AC 220V±10V,50Hz±1 Hz, Fuse 2A
Display liquid crystal display, Resistance display with 4 digits
Data Storage 1000 groups
Max. power consumption 200W, Optional Battery
Overall Dimension Main unit:360*290*170(mm)
string bag:360*230*290(mm)
Weight 6.45KG
Length of test line Standard 10 meters, length can be customized

10A High Precision Portable Transformer DC Winding Resistance Tester

10A High Precision Portable Transformer DC Winding Resistance Tester

Company Profile

Wuhan Mingyang Industrial Technology Co., Ltd. has a professional sales and technical team to deliver premium pre-sales consultation and full technical support.
We maintain an efficient after-sales team to timely resolve all product and technical issues for global customers.
Founded in 2008 and based in Wuhan, China, we are a high-tech enterprise specialized in R&D, production, sales, OEM/ODM customization and after-sales service of power testing and high-voltage inspection equipment.
We keep enhancing independent innovation, upgrading factory facilities and adopting digital management systems. With reliable quality and good reputation, we have built worldwide customer networks and gained global trust. We sincerely look forward to long-term cooperation with you for mutual development.
10A High Precision Portable Transformer DC Winding Resistance Tester
10A High Precision Portable Transformer DC Winding Resistance Tester
Pre-sales Consulting Service
We provide comprehensive and professional pre-sales consulting services. Dedicated sales staff and senior technical engineers are arranged to answer customers’ questions regarding products, technologies and cooperation on a one-on-one basis. We deliver complete and detailed product information throughout the whole process to help customers fully understand product parameters, performances and usage details. All products are reasonably priced with high cost performance to ensure customers get value for money. All quotations are officially verified and stamped by the management team with authenticity and compliance guaranteed. Customers are warmly welcomed to visit our factory for field inspection and business negotiation.
Contract Performance Service
A formal sales contract and supporting technical agreement will be signed by both parties upon confirmation of cooperation intention. Adhering to the principle of integrity, we strictly comply with all clauses of signed contracts and technical agreements to ensure smooth and efficient project implementation. We maintain efficient communication throughout the cooperation, actively follow up with customer demands, and record customers’ inquiries and project schedules in detail to provide continuous professional technical docking and support. In all links including delivery, installation, commissioning and operation training, we respond to customer needs promptly and deliver high-quality services with efficiency and professionalism.
Packaging & Delivery Lead Time
We will arrange product delivery within 5-20 working days after receiving the confirmation of customer payment. All products are professionally packed with high-strength sturdy cartons or wooden boxes. The durable packaging effectively prevents collision and damage during transportation, ensuring the safe arrival of all goods at the destination.
10A High Precision Portable Transformer DC Winding Resistance Tester
Shipping & Transportation Solutions
We offer diversified logistics solutions including express air freight, sea freight and railway transportation. We can recommend the most cost-effective and suitable shipping solution according to customers’ delivery time, budget and destination requirements. If customers appoint their own forwarders, we will fully cooperate and provide a complete set of official customs clearance documents to ensure smooth customs clearance. After shipment, we will continuously track the logistics progress until the goods are successfully and intactly received by customers.
10A High Precision Portable Transformer DC Winding Resistance Tester
Warranty & After-sales Service
We take 100% customer satisfaction as our core service goal. Customers may feedback any product problems at any time, and we will follow up and resolve issues properly in a timely manner. All products are covered by one-year free warranty and lifelong free technical support. We promise to provide exclusive professional solutions within 24 hours upon receipt of customers’ product fault and usage feedback to efficiently solve after-sales problems.
FAQ
1.Are you factory or trading company?
We are a professional manufacturer based in Wuhan, Hubei Province.
2.What is the MOQ?
Please contact our sales team for detailed MOQ.
3.Production & Delivery Time
Standard products: 3-5 working days delivery.
4.Custom orders: around 20 days, subject to quantity and specifications.
5.Payment Terms:50% T/T deposit in advance, 50% balance before shipment.
6.Can I customize products?
Yes, we support full customization according to your technical requirements.
